Direct links to look up
- Motorcycle laws by state.
- Helmet Laws by state
Fuel Filter
Founded in 1924, the AMA has an unparalleled history of pursuing, protecting and promoting the interests of the world's largest and most dedicated group of motorcycle enthusiasts. The AMA focuses on rights, riding and racing through its government relations work, by sanctioning road and off-road riding activities and overseeing professional and amateur racing events.
Oil Filters - Stock Filter Replacements
Yamaha Filter - 4X7-13440-90-00 (replaces - 4X7-13440-01-00)
Yamaha O-Ring - 93210-64297-00
NAPA - PS4935 or P84936
Purolator - ML16804 or ML16805
Fram - PH 6004
STP - SMO-5
WIX - 24935 or 24936
Oil Filters - O.R.K. (Oil Relocation Kit) Filters
Purolator - ML16817
Bosch - 3300
K&N - KN-303 or KN-303C (Chrome)
Napa Gold - 1358
Fram - PH 6017A
Wix - 51358
STP - SDF 13
Hastings - LF-113
-
Exhaust Crush gasket
-
Front 4TR-14613-00
-
rear 4BR-14613-00
-
Clear Turn Signal Lens
-
5VN-83312-10-00
-
Standard Spark Plugs
-
Autolite 4164
-
Champion RA8HC
-
Denso X22EPR-U9
-
NGK DPR7EA-9
-
NGK Iridium
-
DPR7EIX-9
Model Identification
A - Classic
T - Silverado (except 2005 Custom with Flames)
C - California
M - Midnight
F - Flames
R - Raven
W - Pearl White
Years: K=98 L=99 M=00 N=01 P=02 R=03 S=04 T=05 V=06 W=07 X=08 Y=09
Filter Information
For a complete writeup, including details on specific filters, see this PDF
OEM Yamaha Part Numbers
SPARK PLUG GAP 0.8mm (Note: Most plugs come pre-gapped from the factory. It's not recommended that you try to regap Iridium plugs, because the electrode is fragile.)
Tire Pressure
Vstar Custom up to 198lbs |
Vstar Custom over 198lbs |
Vstar Classic up to 198lbs |
Vstar Classic over 198lbs |
Front - 29 psiRear - 33 psi |
Front - 29 psiRear - 36 psi |
Front - 33 psiRear - 33 psi |
Front - 33 psiRear - 36 psi |
* the 198lbs above is rider, passenger and baggage.
How to get sizes of bolts from the part numbers..
The Yamaha microfiche shows the bolt size, you just have to know how to read it. Here is how it works.....
The part number is broken down into 3 parts 99999-06012-00 is an example. The second part, which is 06012 tells you the size. That bolt is 6mm in diameter and 12mm in length. If the second part was 08024 the bolt would be 8mm in diameter and 24mm in length. The first part of the part number tell what type of part it is such as bolt, screw, washer etc. and last 2 digits generally determines the finish such as black, cad, etc
Here is the wiring colors for the bike harness:
Black= Ground
Blue= Running (or low beam on a dual element bulb)
Green= Right Turn Signal
Brown= Left Turn Signal
Yellow= Brake Light (or high beam if using a double element bulb as run / brake)
You have 2 wires on your light, one will be the high beam and the other the low beam, you need to figure out which is which. Connect the low beam to the bikes blue wire and the high beam to the bikes yellow wire. If you have turn signals then just connect them to the brown and green wires. Mounting thećlight on the frame will be the ground connection. Now just one thing, Jeff has advised that grounding to the frame where it will pass thru a bearing may cause some damage so for a side mount you may want to consider running a ground wire to the bikes black wire. You can make your own ground wire in several ways, if you need help then put a post up for that and we'll try to help you out.
XVS65ATV CLASSIC SILVERADO |
XVS65ATVC CLASSIC SILVERADO - California |
XVS65ATV CLASSIC SILVERADO |
XVS65ATVC CLASSIC SILVERADO - California |
XVS65AV CLASSIC |
XVS65AVC CLASSIC - California |
XVS65V CUSTOM |
XVS65VC CUSTOM - California |
XVS65V-M MIDNIGHT CUSTOM |
XVS65VC-M MIDNIGHT CUSTOM - California |
XVS65T-F 2005 CUSTOM WITH FLAMES |
XVS65ASR 2004 CLASSIC (RAVEN) |
